Designing Pcb Boards Multilayer Pcb Design Electronics Pcb Design Layout

  • 1
  • 2
  • 3

Brand Name : YDY

Model Number : PD-4

Certification : ISO13485, IATF16949, ISO9001

Place of Origin : China

MOQ : 1pcs

Price : Negotiatable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100000/month

Delivery Time : 1-10 working days

Packaging Details : Anti-static bag + white pearl cotton (used around the inside of the carton) + carton

Service : Designing Pcb Boards Multilayer Pcb Design Electronics Pcb Design Layout

R&D Range : Consumer Electronics Products,Medical Equipment Products ,Beauty & Personal Care / Health & Medical Products, Electrical Equipment & Supplies,Automotive Parts & Accessories,Plastic Products,Electronic Products Accessories & Telecommunications Products Acce

We can : PCB Layout and Design Industrial Design, Electronics Development, 3D Printing Box Build Services, Mold Design and Manufacture, Product Lifecycle Management,

Type of enterprise : our company has 3 parts concerned with the design, development and production

Why US : Certified Partners , Comprehensive service, Fast and efficient quotations.

R&D team : Covers FGPA antenna design, chip design and so on

Addition service : Algorithm Development Software Development 3D Printing& Enclosure Design

Contact Now

Designing Pcb Boards Multilayer Pcb Design Electronics Pcb Design Layout

Whether you need hardware design, software development or one- stop product development, YDY can provide you with high-quality design services. Our team consists of many experienced electronic engineers, Covers FGPA antenna design, chip design and so on. YDY, always your first choice for PCB design .

I can help you with your product development needs. Either from the start or as additional engineering resources for your engineering division. YDY services are used by both local and international companies, with today's modern communications location is no barrier.

What we need for design&layout?
1) Schematics(.DSN and .SCH suffixes )
2) DXF structure drawing (2D drawing in AutoCAD format, used to position the device and build board size)
3) The component specification (the specification must be with the device size diagram for the establishment and physical one-to-one corresponding package
4) Special requirements

PCB capability :

Service YDY is a product development company specialising in electronic design and product development. Its principle Mark Barber has been involved in electronic design and product development for more than 25 years. With degrees and qualifications in electronics, communication, C programming, CPLD, VHDL, Visual Studio and other areas, a solid knowledgeable background is always a must.
Schematic Diagram Design Our team consists of experienced engineers, such as FPGA senior engineers, antenna experts ect. No matter how complicated the project is, our engineers can design the schematic diagram to meet your requirements.
PCB Design and Layout We use different PCB design softwares to meet your needs: Altium Designer; Cadence Orcad or Allegro; Eagle; KiCAD, which provides very high level PCB design files and full 3D CAD design output capabilities.
Algorithm Development If you meet algorithm problem, we can help you solve it. Our algorithm engineer has rich experience in image processing, data processing and so on.
Shape Retangular, Round, Slots, Cutouts, Complex, Irregular
Cutting Shear, V-score, Tab-routed
Board Thickness 0.2-4mm, regular 1.6mm
Copper Thickness 0.5-4oz, regular 1oz
Solder Mask Green, Red, Blue, Yellow, etc.
Silk Screen White, Black, etc.
Silk Screen Min Line Width 0.006" or 0.15mm
Min Trace/Gap 0.1mm or 4mils
Min Drill Hole Diameter 0.01",0.25mm or 10mils
Surface Finish HASL, ENIG, OSP, etc.

Designing Pcb Boards Multilayer Pcb Design Electronics Pcb Design Layout

Shenzhen Yideyi Technology Co., Ltd is an electronic designer that lets printed circuit board (PCB) designers seamlessly connect schematic diagrams, component placement, PCB routing, and comprehensive library content.

Designing Pcb Boards Multilayer Pcb Design Electronics Pcb Design Layout

Our advantage :
1. we have our own PCBA factory with more than 12 SMT production line.
2. We can Customize The Product According To Your Idea and turn it into final products.
3. OEM&ODM electronic design, industrial design and mechanical design experience from mold design to manufacturing with one-stop service
4. Our designers and engineers all use AUTO CAD,Pro/E,UG and Soliworks software to check 2D and 3D drawings.
